iQ700 downdraft hood 90 cm clear glass, BlackLD98WMM66
LD98WMM66
1 / 0
iQ700 downdraft hood 90 cm clear glass, BlackLD98WMM66
LD98WMM66
$4,999.00
List Price
Where to buy
Click here to find the nearest Siemens retailer
iQ700 downdraft hood 90 cm clear glass, BlackLD98WMM66
LD98WMM66
$4,999.00
List Price
Where to buy
Click here to find the nearest Siemens retailer
Technical Overview
Installation type
Built-in
Width
90 cm
Cooktop-based rangehood control
Yes
Noise level
62 dB(A) re 1 pW
climate control Sensor
Yes
Operating mode
Exhaust / Recirculation (Accessory available separately)
Max. ducted extraction
519 m³/h
Boost position air extraction
833 m³/h
Key Features
Commitment To Excellence
Specifications
Width
90 cm
Colour of the body
Black
Installation type
Built-in
Operating mode
Exhaust / Recirculation (Accessory available separately)
Total power of the motors
300 W
Controls
touch control, Via app
Number of power settings
3-stages + 2 intensive settings
Max. ducted extraction
519 m³/h
Boost position air extraction
833 m³/h
Sound power at max. speed (2010/30/EC)
62 dB
Sound power boost (2010/30/EC)
71 dB
Max. recirculation
456 m³/h
Boost position output recirculating
596 m³/h
Sound power at max. speed (recirculation)
66 dB
Sound power boost (recirculation)
71 dB
Grease filter material
Washable stainless steel
Energy efficiency rating
4 star
Total annual energy consumption
37.8 kWh/year
Included user manuals
[DE, FR, NL]
Voltage
220-240 V
Height of the appliance
709 mm
Width of the appliance
912 mm
Depth of the product
140 mm
Dimensions of the packed product
610x1140x870 mm
Height of the chimney
GENERAL.N_A mm
Diameter of air outlet
150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
39.7 kg
Handle bar
Not applicable
Appliance height exhaust air max
959 mm
Appliance height exhaust air min
709 mm
Appliance height recirculating max
959 mm
Appliance height recirculating min
709 mm
Maximum width for installation
854 mm
Minimum width for installation
854 mm
Depth for installation
123 mm
1 / 0
climate control Sensor
Yes
iQdrive motor
Yes
Extremely silent appliances
No
Clean filter reminder
Yes
Boost mode
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
None
Total power of the lamps
GENERAL.N_A W
Color temperature
Not applicable
Illumination type softlight
No
Light colour customisable by Home Connect
No
Ambient light
Yes
Home Connect
Yes
Home Connect Features
Remote Monitoring and Control
Cooktop-based rangehood control
Yes
Smart Hood Automatic
No
