Technical Overview
Installation type
Wall-mounted
Width
90 cm
Cooktop-based rangehood control
Yes
Sound pressure recirculated air level 2
57 dB(A) re 1 pW
climate control Sensor
Yes
Operating mode
Exhaust / Recirculation (Accessory available separately)
Max. ducted extraction
602 m³/h
Boost position air extraction
965 m³/h
Key Features
Specifications
Width
90 cm
Colour of the body
Stainless steel
Installation type
Wall-mounted
Operating mode
Exhaust / Recirculation (Accessory available separately)
Total power of the motors
260 W
Controls
Via app
Number of power settings
3-stages + 2 intensive settings
Max. ducted extraction
602 m³/h
Boost position air extraction
965 m³/h
Sound power at max. speed (2010/30/EC)
64 dB
Sound power boost (2010/30/EC)
73 dB
Max. recirculation
462 m³/h
Boost position output recirculating
561 m³/h
Sound power at max. speed (recirculation)
68 dB
Sound power boost (recirculation)
72 dB
Grease filter material
Washable stainless steel
Energy efficiency rating
A+
Total annual energy consumption
37.7 kWh/year
Included user manuals
[EN]
Height of the appliance
46 mm
Width of the appliance
898 mm
Depth of the product
500 mm
Dimensions of the packed product
585x650x970 mm
Height of the chimney
582-908/568-1018 mm
Minimum distance above an electric cooktop (EU)
550 mm
Minimum distance above a gas cooktop
650 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
Yes
Length electrical supply cord
130 cm
Net weight
19.4 kg
Handle bar
Not applicable
Appliance height exhaust air max
954 mm
Appliance height exhaust air min
614 mm
Appliance height recirculating max
1064 mm
Appliance height recirculating min
614 mm
1 / 0
climate control Sensor
Yes
iQdrive motor
Yes
Extremely silent appliances
No
Clean filter reminder
Yes
Boost mode
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
Not applicable
Number of lights
3
Total luminance
578 lux
Illumination type softlight
Yes
Light colour customisable by Home Connect
Yes
Ambient light
No
Home Connect
Yes
Home Connect Features
iService Remote, Remote Monitoring and Control
Cooktop-based rangehood control
Yes
Smart Hood Automatic
No
